Característiques

●Fully compatible with ITU-T G.984.1/2/3/4

●Support downlink rate 2.448Gbit/s, uplink rate is 1.244Gbit/s

●Support Dying-Gas detection and reporting

●Support rogue ONUdetecció

●Support Tag/Untag Ethernet frame of 802.1 and Q 802.3 standard, support QinQ

●Support for flexible flow classification, maximum 520 flow classification rules

●Support link error monitoring and loop monitoring

●Support a variety of multicast forwarding mode, support multicast replication

●Auto-negotiation and manual settings of Ethernet supporting rate, duplex mode

●UNI interface supports STP/RSTP protocol

●Provide QoS guarantees for different priority business through SLA restraining, Policing, queue management scheduling / congestion avoidance, discarding management mode

●Support flow control based on entrance , choose Pause frame reaction pressure to Packet loss for the business beyond

Especificació

Article	Paràmetres	Especificació
Interfície	PON Port	1 G/EPON port(EPON PX20 plus and GPON Class B plus ) Wavelength:Tx1310nm,Rx 1490nm SC/UPC connector Receiving sensitivity: Less than or equal to -28dBm Transmitting optical power: 0 plus 4dBm Transmission distance: 20KM
Ethernet Port(LAN)	1GE Auto-negotiation RJ45 ports Full Duplex / Half-Duplex RJ45, Auto-MDI/MDI-X Transmission Distance 100 Meter
Power Supply Port	12V DC input
Gestió	Network Management	Standard compliant OMCI interface as defined by ITU-T G.984.4 Support WEB management
Gestió Funció	Status monitor, Configuration management, Alarm management, Log management
Ambiental Especificacions	Shell	Plastic casing
Poder	External 12V 0.5A DC power supply adapter Power consumption: <>
Dimensions	110mm(L) x90mm(W) x25mm (H)
Medi ambient	Operating Temperature:0-50 degree Storage Temperature:-40-85 degree Operating Humidity:10 percent -90 percent (Non-condensing) Storage Humidity:10 percent -90 percent (Non-condensing)

Paràmetres del programari

Technical item
Bàsic	Support Bridge and Routing DHCP/PPPOE/Static IP Support Static route Support NATSupport MPCP discoverister Support authentication Mac/Loid/Mac plus Loid Support Triple Churning Support DBA bandwidth Support auto-detecting, auto-configuration, and auto firmware upgrade Support authentication SN/Psw/Loid/Loid plus Psw
Alarma	Support Dying Gasp Support Port Loop Detect Support Eth Port Los
LAN	Support Port rate limiting Support Loop detection Support Flow control Support Storm control
VLAN	Support VLAN tag mode Support VLAN transparent mode Support VLAN trunk mode(max 8 vlans) Support VLAN 1:1 translation mode(max 8 vlans) Auto VLAN detection
Multicast	Support IGMPv1/v2 Support IGMP Snooping Max Multicast vlan 8 Max Multicast Group 64
QoS	Support 4 queues Support SP and WRR Support 802.1P
Gestió	Support CTC OAM 2.0 and 2.1 Support ITUT984.x OMCI Support WEB Support TELNET
